Electronic Weighing Scale Load Cell Sensor 10Kg

It is mainly used in check weighing. Features: Aluminum-alloy, Colourless anodized, Hermetically sealed with glue to IP65. Supports Pan size upto 250mm X 350mm Easy to mounting High Accuracy Dimensions – 130x22x30 mm (Thread Hole : 4-M6) Application: Mainly Used for Table Top Machines Bench Scale Price Computing Scale Retail Scales Electronic Counting Scales Check Weighing Scales etc Specifications: Nominal Output 2.0 ? 0.1 mV/V (mili Volt per Volt) Precision C2 / C3 (0.017% & 0.02% FSO comprehensive error) Excitation Voltage 9 VDC – Maximum 12 VDC Platter Size 250mm x 350mm Safe Load 120% of Rated Capacity Ultimate Load 150% of Rated Capacity Non Linearity <?0.03% of FSO (Full Scale Output) Creep (30 minutes) <?0.025% of FSO Zero Balance <?1% of FSO Input Resistance 400 ? 10 ohms Output Resistance 350 ? 5 ohms Insulation resistance Above 5000 Mega ohms Temp. Compensation -10oC to 40oC Temp. Effect on zero & span < 0.03% FSO/10oC Material Alluminium alloy, Colourless anodized Cable 4mm, 0.42 mts SKU: RM002048 Category: Load Pressure Flow and Vibration Sensor Warehouse Code: R00015-S01-P02-Z01
